sensor

1 / 1.8 Inch 8.42 megapixel Sony CMOS sensor

Pixel size

2.0µmx2. 0µm

USB interface

USB2. 0 × 2 (mouse, USB flash disk)

HDMI output

3840 * 2160 60 frames / 1920 * 1080 60 frames

Lens interface

C interface

exposure

One touch exposure / auto exposure

white balance

One key white balance / automatic white balance

storage

Support USB flash disk storage

Auxiliary function

Support: arbitrary adjustment of line width measurement, font measurement, element color, font color, calibration color, etc

measure

New measuring system, point spacing, rectangle, concentric circle, polygon, three-point circle, center distance, circle line distance, angle, radian, point line distance, parallel line and broken line

input voltage

DC 5V-12V

Scribe

It supports 8 straight lines, and the color and position are adjustable


Support horizontal / flip up and down

Menu language

English / Chinese / traditional
