H2602T-Video microscope-Shenzhen Oseecam Technology Co., Ltd.

Product name: H2602T

◆Using 2 million pixels Sony's new generation of high dynamic range CMOS image sensor;
◆Using 1/2-inch image sensor, the viewing angle is wider than 1/3-inch;
◆Pixel size: 3.75um × 3.75um;
◆HDMI 1080P 60 frame image output;
◆Optical magnification: 0.7-4.5X;
◆Magnification: 20-135 times continuously adjustable (optional 10-270 times)
◆Support photo and video, JPG format;
◆Support manual one-key exposure;
◆Support manual one-key white balance, red, green and blue adjustable;
◆Provide 8 line drawing functions, the line color, thickness and position are adjustable;
◆Provide center cross line display/close;
◆Support U disk storage; mouse operation;
◆The picture is clearer without shaking;
◆Support Chinese and English menu languages (default English);
◆Support horizontal and inverted mirroring;

Image display
Information

model	H2602T
Lens	HD lens 0.7*4.5X+0.5X objective lens (0.5X objective lens optional)
Ring light	T60, adjustable (frosted light source optional)
Bracket	Black base plate bracket, adjustable (optional universal bracket)
monitor	Standard HDMI interface 21.5-inch display is optional, and other displays of various sizes can also be connected
multiple	20-135 times (optional 10-270 times)
sensor	1/2 inch 2 million pixel Sony CMOS sensor
Pixel size	3.75µm × 3.75µm
HDMI output	1920*1080 60 frames
USB output	USB2.0 (plug in U disk or mouse)
storage	U disk storage, maximum support 64GB
Input voltage	DC 5V-12V
Underline	Provide 8 line drawing functions, line color, thickness, position adjustable
Centerline	support
Menu language	English/Chinese/Traditional
mouse	Support mouse operation, take photos and videos
